Access Control Pedestrian IR Sensor Counter Turnstile Coin Operated
| SPECIFICATIONS |
| Type | full automatic |
| Material | 304 Stainless Steel |
| Communication | TCP/IP |
| Passage direction | bidirectional |
| Working temperature | -30℃-- 80℃ |
| Working humidity | 5%-90% |
| Swing arm speed | 1s |
| Passage width | 600mm |
| Size | 1400*160*990mm |
Characters of Turnstile Gate
1 ) The entire system runs smoothly, with a small noise and free of mechanical impact.
2 ) It has failure self-detect and alarm indication function, facilitating maintenance and application for the users.
3 ) DC Brushless Motor, Maintenance Free
4 ) It is provided with multiple operation modes for selection. It can either read card in double way for flow limit, or reading card in a way while barring in the other, or read card in a way while free passage in the other. Moreover, the operation mode of turnstile may be set up with the built-in small keyboard.
5 ) It has automatic function of opening or closing when power off.
6 ) The equipment is provided with a unified, standard electric interface and is available to be integrated with various read/write facilities to facilitate the system integration. It is able to realize far end control and management with the help of administrative computer.
7 ) It has a function of reading card with or without memory, and it may be set up with the built-in small keyboard in accordance with the requirements of the users.
8 ) Counting the passing people number automatically, and with LED display
9 ) Direction indicator function, showing passing or prohibiting for the people
10 ) Prohibiting opposite direction passing, one side reading the card, the other side will lock when you passing force; the locking time can be set, and unlocked by the card.
11 ) Prohibiting illegal passing, the turnstile without the card, the locking time can be set, and unlocked by the card.
12 ) Self resetting function, the system will cancel the people passing right when reading the card but not passing, the time can be set.
13 ) Anti-hit against function, when the turnstile touches the passing people, it will stop and after several seconds, it will turn again.
14 )TCP/IP Communication function
